The average power of a FreeDV signal is surprisingly hard to measure as the parallel carriers produce a waveform that has many peaks an troughs as the various carriers come in and out of phase with each other. Peter, VK3RV has been working on some interesting experiments to measure FreeDV power using calorimeters. His work got me thinking about FreeDV power and in particular ways to improve the Peak to Average Power Ratio (PAPR).
I’ve messed with a simple clipper for FreeDV 700C in the past, but decided to take a more scientific approach and use some simulations to measure the effect of clipping on FreeDV PAPR and BER. As usual, asking a few questions blew up into a several week long project. The usual bugs and strange, too good to be true initial results until I started to get results that felt sensible. I’ve tested some of the ideas over the air (blowing up an attenuator along the way), and learnt a lot about PAPR and related subjects like Peak Envelope Power (PEP).
The goal of this work is to explore the effect of a clipper on the average power and ultimately the BER of a received FreeDV signal, given a transmitter with a fixed peak output power.
Clipping to reduce PAPR
In normal operation we adjust our Tx drive so the peaks just trigger the ALC. This sets the average power at Ppeak – PAPR Watts, for example Pav = 100WPEP – 10dB = 10W average.
The idea of the clipper is to chop the tops off the FreeDV waveform so the PAPR is decreased. We can then increase the Tx drive, and get a higher average power. For example if PAPR is reduced from 10 to 4dB, we get Pav = 100WPEP – 4dB – 40W. That’s 4x the average power output of the 10dB PAPR case – Woohoo!
In the example below the 16 carrier waveform was clipped and the PAPR reduced from 10.5 to 4.5dB. The filtering applied after the clipper smooths out the transitions (and limits the bandwidth to something reasonable).
However it gets complicated. Clipping actually reduces the average power, as we’ve removed the high energy parts of the waveform. It also distorts the signal. Here is a scatter diagram of the signal before and after clipping:
The effect looks like additive noise. Hmmm, and what happens on multipath channels, does the modem perform the same as for AWGN with clipped signals? Another question – how much clipping should we apply?
So I set about writing a simulation (papr_test.m) and doing some experiments to increase my understanding of clippers, PAPR, and OFDM modem performance using typical FreeDV waveforms. I started out trying a few different compression methods such as different compander curves, but found that clipping plus a bandpass filter gives about the same result. So for simplicity I settled on clipping. Throughout this post many graphs are presented in terms of Eb/No – for the purpose of comparison just consider this the same thing as SNR. If the Eb/No goes up by 1dB, so does the SNR.
Here’s a plot of PAPR versus the number of carriers, showing PAPR getting worse with the number of carriers used:
Random data was used for each symbol. As the number of carriers increases, you start to get phases in carriers cancelling due to random alignment, reducing the big peaks. Behaivour with real world data may be different; if there are instances where the phases of all carriers are aligned there may be larger peaks.
To define the amount of clipping I used an estimate of the PDF and CDF:
The PDF (or histogram) shows how likely a certain level is, and the CDF shows the cumulative PDF. High level samples are quite unlikely. The CDF shows us what proportion of samples are above and below a certain level. This CDF shows us that 80% of the samples have a level of less than 4, so only 20% of the samples are above 4. So a clip level of 0.8 means the clipper hard limits at a level of 4, which would affect the top 20% of the samples. A clip value of 0.6, would mean samples with a level of 2.7 and above are clipped.
Effect of clipping on BER
Here are a bunch of curves that show the effect of clipping on and AWGN and multipath channel (roughly CCIR poor). A 16 carrier signal was used – typical of FreeDV waveforms. The clipping level and resulting PAPR is shown in the legend. I also threw in a Tx diversity curve – sending each symbol twice on double the carriers. This is the approach used on FreeDV 700C and tends to help a lot on multipath channels.
As we clip the signal more and more, the BER performance gets worse (Eb/No x-axis) – but the PAPR is reduced so we can increase the average power, which improves the BER. I’ve tried to show the combined effect on the (peak Eb/No x-axis) curves which scales each curve according to it’s PAPR requirements. This shows the peak power required for a given BER. Lower is better.
- The 0.8 and 0.6 clip levels work best on the peak Eb/No scale, ie when we combine effect of the hit on BER performance (bad) and PAPR improvement (good).
- There is about 4dB improvement across a range of operating points. This is pretty signficant – similar to gains we get from Tx diversity or a good FEC code.
- AWGN and Multipath improvements are similar – good. Sometimes you get an algorithm that works well on AWGN but falls in a heap on multipath channels, which are typically much tougher to push bits through.
- I also tried 8 carrier waveforms, which produced results about 1dB better, as I guess fewer carriers have a lower PAPR to start with.
- Non-linear techniques like clipping spread the energy in frequency.
- Filtering to constrain the frequency spread brings the PAPR up again. We can trade off PAPR with bandwidth: lower PAPR, more bandwidth.
- Non-linear technqiques will mess with QAM more. So we may hit a wall at high data rates.
Testing on a Real PA
All these simulations are great, but how do they compare with operation on a real HF radio? I designed an experiment to find out.
First, some definitions.
The same FreeDV OFDM signal is represented in different ways as it winds it’s way through the FreeDV system:
- Complex valued samples are used for much of the internal signal processing.
- Real valued samples at the interfaces, e.g. for getting samples in and out of a sound card and standard HF radio.
- Analog baseband signals, e.g. voltage inside your radio.
- Analog RF signals, e.g. at the output of your PA, and input to your receiver terminals.
- An electromagnetic wave.
It’s the same signal, as we can convert freely between the representations with no loss of fidelity, but it’s representation can change the way measures like PAPR work. This caused me some confusion – for example the PAPR of the real signal is about 3dB higher than the complex valued version! I’m still a bit fuzzy on this one, but have satisfied myself that the PAPR of the complex signal is the same as the PAPR of the RF signal – which is what we really care about.
Another definition that I had to (re)study was Peak Envelope Power (PEP) – which is the peak power averaged over one or more carrier cycles. This is the RF equivalent to our “peak” in PAPR. When driven by any baseband input signal, it’s the maximum RF power of the radio, averaged over one or more carrier cycles. Signals such as speech and FreeDV waveforms will have occasional peaks that hit the PEP. A baseband sine wave driving the radio would generate a RF signal that sits at the PEP power continuously.
Here is the experimental setup:
The idea is to play canned files through the radio, and measure the average Tx power. It took me several attempts before my experiment gave sensible results. A key improvement was to make the peak power of each sampled signal the same. This means I don’t have to keep messing with the audio drive levels to ensure I have the same peak power. The samples are 16 bits, so I normalised each file such that the peak was at +/- 10000.
Here is the RF power sampler:
It works pretty well on signals from my FT-817 and IC-7200, and will help prevent any more damage to RF test equipment. I used my RF sampler after my first attempt using a SMA barell attenuator resulted in it’s destruction when I accdentally put 5W into it! Suddenly it went from 30dB to 42dB attenuation. Oops.
For all the experiments I am tuned to 7.175 MHz and have the FT-817 on it’s lowest power level of 0.5W.
For my first experiment I played a 1000 Hz sine wave into the system, and measured the average power. I like to start with simple signals, something known that lets me check all the fiddly RF kit is actually working. After a few hours of messing about – I did indeed see 27dBm (0.5W) on my spec-an. So, for a signal with 0dB PAPR, we measure average power = PEP. Check.
In my next experiment, I measured the effect of ALC on TX power. With the FT-817 on it’s lowest power setting (0.5W), I increased the drive until just before the ALC bars came on: Here is the relationship I found with output power:
So the ALC really does clamp the power at the peak value.
On to more complex FreeDV signals.
Mesuring the average power OFDM/parallel tone signals proved much harder to measure on the spec-an. The power bounces around over a period of several seconds the ODFM waveform evolves which can derail many power measurement techniques. The time constant, or measurement window is important – we want to capture the total power over a few seconds and average the value.
After several attempts and lots of head scratching I settled on the following spec-an settings:
- 10s sweep time so the RBW filter is averging a lot of time varying power at each point in the sweep.
- 100kHz span.
- RBW/VBW of 10 kHz so we capture all of the 1kHz wide OFDM signal in the RBW filter peak when averaging.
- Power averaging over 5 samples.
The two-tone signal was included to help me debug my spec-an settings, as it has a known (3dB) PAPR.
Here is a table showing the results for several test signals, all of which have the same peak power:
||PAPR Theory/Sim (dB)
||PAPR Mesured (dB)
||sine wave at 1000 Hz
||two tones at 800 and 1200Hz
||700D test frames unclipped
||700D test frames clipped at 0.8
||700D with real speech payload data
Click on the file name to listen to a 5 second sample of the sample. The lower PAPR (higher average power) signals sound louder – I guess our ears work on average power too! I kept the drive constant and the PEP/peak just happened to hit 26dBm. It’s not critical, as long as the drive (and hence peak level) is the same across all waveforms tested.
Note the two tone “control” is 1dB off (4dB measured on a known 3dB PAPR signal), I’m not happy about that. This suggests a spec-an set up issue or limitation on my spec-an (e.g. the way it averages power).
However the other signals line up OK to the simulated values, within about +/- 0.5dB, which suggests I’m on the right track with my simulations.
The modulated 700D test frame signals were generated by the Octave ofdm_tx.m script, which reports the PAPR of the complex signal. The same test frame repeats continuously, which makes BER measurements convenient, but is slightly unrealistic. The PAPR was lower than the ve9qrp signal which has real speech payload data. Perhaps because the more random, real world payload data leads to occasional frames where the phase of the carriers align leading to large peaks.
Another source of discrepancy is the non flat frequency filtering in the baseband audio/crystal filter path the signal has to flow through before it emerges as RF.
The zero-span spec-an setting plots power over time, and is very useful for visualing PAPR. The first plot shows the power of our 1000 Hz sine signal (yellow), and the two tone test signal (purple):
You can see how mixing just two signals modulates the power over time, the effect on PAPR, and how the average power is reduced. Next we have the ve9qrp signal (yellow), and our clip 0.8 signal (purple):
It’s clear the clipped signal has a much higher average power. Note the random way the waveform power peaks and dips, as the various carriers come into phase. Note very few high power peaks in the ve9qrp signal – in this sample we don’t have any that hits +26dBm, as they are fairly rare.
I found eye-balling the zero-span plots gave me similar values to non-zero span results in the table above, a good cross check.
- Clipping is indeed improving our measured average power, but there are some discrepencies between the measured and PAPR values estimated from theory/simulation.
- Using a SDR to receive the signal and measure PAPR using my own maths might be easier than fiddling with the spec-an and guessing at it’s internal algorithms.
- PAPR is worse for real world signals (e.g. ve9qrp) than my canned test frames due to relatively rare alignments of the carrier phases. This might only happen once every few seconds, but significantly raises the PAPR, and hurts our average power. These occasional peaks might be triggering the ALC, pushing the average power down every time they occur. As they are rare, these peaks can be clipped with no impact on perceived speech quality. This is why I like the CDF/PDF method of setting thresholds, it lets us discard rare (low probability) outliers that might be hurting our average power.
Conclusions and Further work
The simulations suggest we can improve FreeDV by 4dB using the right clipper/filter combination. Initial tests over a real PA show we can indeed reduce PAPR in line with our simulations.
This project has lead me down an interesting rabbit hole that has kept me busy for a few weeks! Just in case I haven’t had enough, some ideas for further work:
- Align these clipping levels and filtering to FreeDV 700D (and possibly 2020). There is existing clipper and filter code but the thresholds were set by educated guess several years for 700C.
- Currently each FreeDV waveform is scaled to have the same average power. This is the signal fed via the sound card to your Tx. Should the levels of each FreeDV waveform be adjusted to be the same peak value instead?
- Design an experiment to prove BER performance at a given SNR is improved by 4dB as suggested by these simulations. Currently all we have measured is the average power and PAPR – we haven’t actually verified the expected 4dB increase in performance (suggested by the BER simulations above) which is the real goal.
- Try the experiments on a SDR Tx – they tend to get results closer to theory due to no crystal filters/baseband audio filtering.
- Try the experiments on a 100WPEP Tx – I have ordered a dummy load to do that relatively safely.
- Explore the effect of ALC on FreeDV signals and why we set the signals to “just tickle” the ALC. This is something I don’t really understand, but have just assumed is good practice based on other peoples experiences with parallel tone/OFDM modems and on-air FreeDV use. I can see how ALC would compress the amplitude of the OFDM waveform – which this blog post suggests might be a good thing! Perhaps it does so in an uncontrolled manner – as the curves above show the amount of compression is pretty important. “Just tickling the ALC” guarantees us a linear PA – so we can handle any needed compression/clipping carefully in the DSP.
- Explore other ways of reducing PAPR.
To peel away the layers of a complex problem is very satisfying. It always takes me several goes, improvements come as the bugs fall out one by one. Writing these blog posts oftens makes me sit back and say “huh?”, as I discover things that don’t make sense when I write them up. I guess that’s the review process in action.
